Creality CR-Scan Ferret
Upgraded 3D Scanner
Upgraded 3D Scanner
Introducing the latest addition to the lineup, the Creality CR-Scan Ferret 3D Scanner, a remarkable advancement from its predecessor, the CR-Scan Lizard. This enhanced model brings you faster scanning capabilities and expanded scene compatibility. With improved versatility, the Ferret excels at scanning a diverse array of scenes, whether indoors or outdoors. This innovation promises increased playability and opens up new avenues for object scanning and exploration.
Ferret is significantly less expensive than comparable scanners, and is comparable to the cost of 3D printers such as the Ender 3 series, while providing excellent scanning performance. It is your best option for creating a masterpiece.
It is easy to hold with one hand, weighs only 105 grams (the weight of an orange), and fits easily into a pocket or backpack. Simply release your creativity whenever and wherever you want.
The two modes can be switched depending on the situation. The high-accuracy mode is suitable for small and medium-sized objects, whereas the wide range scanning mode allows for fast scanning of large objects.
Up to 0.1mm accuracy and 0.16mm 3D resolution ensure superior dimensional accuracy and detail capture.
The single capture range is up to 560*820mm, resulting in a larger scanning area and a more flexible scanning distance for medium and large objects.
Built with ASIC deep computing chips, it provides deep processing for megapixel images at 60 frames per second, with a processing speed that is more than ten times faster than that of general chips. The scanning rate is up to 30fps, allowing it to obtain 3D point clouds more quickly and thereby significantly improving the scanning fluency.
An integrated high-resolution colour camera records full colour textures for 3D models, displaying the object's true colour, and delivering unmatched scanning outcomes.
It is portable and simple to use, comes with a stand that can be used in handheled or turntable modes, is compatible with computer and phone, and is so versatile that you will be glad to have one.
Ferret has higher environmental adaptability and maintains excellent performance even in bright sunlight thanks to advanced optical technology and an intelligent algorithm.
Because of its low power consumption, it can be powered by a 5V power bank or even your Android phone. You can begin scanning at any time.
Product Name
CR-Scan Ferret
Resolution/Point Distance
0.16mm
Working Distance
150~700mm
Frame Rate/Scan Speed
Up to 30 fps
Color Texture
Support
Machine Weight
150g
Alignment
Feature/Marker/Color
Output Format
OBJ/STL/PLY
Machine Size
120*30*26mm
Light Source
NIR
Tracking Mode
Visual Tracking
Connection Mode
USB 3.0/2.0
Compatible System
Android / Win 10 / 11 (64-bit) / Mac OS
Accuracy
0.1mm
Single Capture Range
560*820mm@700mm
Minimum Scanning
50*50*50mm
Outdoor Scanning
Support Scanning in Bright Sunlight
