Elegoo Neptune 4 Pro 3D Printer

Fast | Stable | Precise

The Elegoo Neptune 4 Pro 3D Printer is a fast, stable, and powerful FDM printer that brings significant enhancements to the Elegoo printer family. With its high-performance mainboard and remarkable top speed of 500 mm/s, it delivers exceptional printing capabilities and is compatible with Klipper firmware. What sets the Neptune 4 Pro apart from the Neptune 4 model are three standout features: a dual heating bed with two independent heating areas for precise temperature control, an all-metal frame for enhanced durability and stability, and all-metal linear rails that ensure smooth and accurate movement of the print head. These improvements make the Neptune 4 Pro an ideal choice for users seeking superior performance and reliability in their 3D printing endeavors.

Features Of Elegoo Neptune 4 Pro 3D Printer


Pre-installed Klipper Firmware - Speed Up Printing with Klipper

The Klipper motherboard and ARM 64-bit 1.5G main frequency quad-core processor enable the Neptune 4 Pro to process and execute commands more quickly, enabling you to finish your print projects quickly and effectively. Neptune 4 Pro can print at up to 500mm/s. You can start printing right away without having to deal with the hassle of installing firmware thanks to our pre-installed Klipper firmware. Additionally, it supports pressure advance, which aids in predicting nozzle pressure for more precise and consistent extrusion and less filament ooze and blobbing, input shaping, which aids in removing artefacts and resonances on the model surface.

Elegoo Neptune 4 Pro comes with Pre-installed Klipper Firmware
Elegoo Neptune 4 Pro comes with Pre-installed Klipper FirmwareElegoo Neptune 4 Pro comes with Pre-installed Klipper Firmware

Dual Gear Direct Drive Extruder - Powerful Extrusion Mechanism

Dual Gear Direct Drive Extruder - Powerful Extrusion Mechanism

Another important component that guarantees consistent and smooth extrusion is the dual-gear direct drive extruder, which weighs only 75% as much as the Neptune 3 Pro. The dual-gear design and 5.2:1 reduction ratio guarantee a tight hold on the filament and keep the flexible filament from slipping and grinding. The throat pipe of the copper-titanium bi-metal has a special air duct design for quicker throat pipe heat dissipation and less nozzle clogging. You can experiment with a wider range of materials, including PLA, PETG, ABS, TPU, and high-temp filaments like nylon, thanks to the 300°C high-temp nozzle with an extended hotend design that fully melts the filament.

Intelligent Segmented Heatbed - PEI Magnetic Platform

Intelligent Segmented Heatbed - PEI Magnetic Platform

The intelligent segmented heatbed and hot bed overheat protection switch on the ELEGOO Neptune 4 Pro help to increase efficiency and save energy while preventing thermal runaway from damaging or igniting the hot bed. The heatbed is perfect for smaller models because it can be set to 100W to heat only the centre area (120mm×120mm). The heatbed can be set to 250W for larger models, heating the entire surface area. Additionally, the two partitions can be manually adjusted to provide for flexible temperature changes. Simply gently bend the print steel plate to release or pop off the prints using the PEI magnetic platform, which has a special coating and spring steel sheet for good adhesion and anti-warping.

Stable and Quiet Printing

Stable and Quiet Printing

With silent drivers for all axes and noise levels below 50db, the ELEGOO Neptune 4 Pro 3D Printer is designed for quiet and precise printing. Its durable POM V-guide wheels move quietly, smoothly, and precisely. The Z-axis dual lead screw + Z-axis dual motor design improves synchronisation, increasing print head accuracy and stability.

Efficient Cooling System

Efficient Cooling System

The Neptune 4 Pro has two thickened 4015 ball bearing cooling fans on either side of the print head and four 4020 ball bearing blower fans behind it to ensure quick and omnidirectional cooling of freshly deposited models. This cooling system prevents problems like warping or deformation by allowing the hot filament to bond quickly for better overhang and bridge results even at a fast printing speed.

Removable Capacitive Touchscreen

Removable Capacitive Touchscreen

The 4.3-inch removable capacitive touchscreen has a model preview function and a printing pause function for your convenience. It can be used either hand-held or fixed to the base. For viewing the model printing in low light, the gantry has a 30 bead LED light strip, a hood, and an LED light on the nozzle.

More Practical Features

  • Because of the printer's power loss recovery feature, printing can resume after an unplanned power outage. With a filament detection sensor, the printer will halt and sound an alarm when the filament runs out or breaks.
  • Support LAN networking printing. After connecting, you can remotely control and keep an eye on your printer on the same network using the WEB terminal.
  • The widened Y-axis profile ensures a stable printing platform, and the hand-twist knob on the XY-axis belt tensioner makes adjustments simple.
  • To conveniently observe model printing in low light, the button on the screen can be used to turn on the LED light bar and nozzle LED light on the gantry.
Elegoo Neptune 4 Pro 3D Printers has More Practical Features

Technical Specifications

Elegoo Neptune 4 Pro 3D Printer

Build Specifications

Build Volume
(X×Y×Z)
225×225×265 mm

Temperature

Max Hotend Temperature300 °C
Max Bed Temperature110 °C

Speed & Precision

Max Print Speed500 mm/s
Typical Print Speed250 mm/s
Min Layer Height0.1 mm
Max Layer Height0.35 mm

Nozzle & Extruder

Default Nozzle Diameter0.4 mm
Min Nozzle Diameter0.2 mm
Max Nozzle Diameter0.8 mm
Number of Extruders1
Extruder TypeDirect Drive (Dual-Gear, All-Metal)

Connectivity & Features

ConnectivityWi-Fi, USB, LAN
Auto Bed LevelingYes (121-Point Auto)
Filament Run-out SensorYes
Power Loss RecoveryYes

Physical

Weight10 kg
Printer Dimensions
(W×D×H)
475×445×515 mm

Compatibility

Compatible Filament TypesPLA, TPU, PETG, ABS, ASA, Nylon
Filament Diameter1.75 mm

Other Specs

Printing TechnologyFFF
Motion SystemBed-slinger (Klipper)
FrameOpen
Max Acceleration8000 mm/s²
Printing Accuracy±0.1 mm
Display4.3" Color Touch Screen
Build PlatePEI Spring Steel Sheet
File FormatsSTL, OBJ, 3MF
Slicer SoftwareElegoo Cura, Elegoo Slicer
Cloud IntegrationElegoo Link
